C10100 Copper Wire

Product Description:

Copper wire refers to a wire drawn from hot-rolled copper bars without annealing (but smaller wires may require intermediate annealing), which can be used for weaving nets, cables, copper brush filter nets, etc.

Consulting Products:

8618100378292

candy@qdgssteel.com

Product Details

parameter

Chemical Composition

Mechanical Properties:

Item	Copper Wire
Grade	C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920, C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300, C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200, C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000, C44300,C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70620, C71000,C71500,C71520,C71640,C72200,T1,T2,T3,etc
Standard	JIS ASTM DIN EN ISO
Diameter	0.1-5mm/custom
Length	custom
Surface	mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc
Application	Building, industry etc
Payment Terms	30% T/T in advance as deposit,70% balance against the B/L copy or 100% irrevocable L/C at sight
Delivery time	5-15 days after receiving L/C or deposit
Remark	Specific requirement of alloy grade,temper or specification can be discussed at your request

Grade			Chemical Composition(%)
	GB	JIS	Cu+Ag	P	Bi	Sb	As	Fe	Ni	Pb	Sn	S	Zn	O
Refined Copper	T1	C1020	99.95	0.001	0.001	0.002	0.002	0.005	0.002	0.003	0.002	0.005	0.005	0.02
	T2	C1100	99.9	-	0.001	0.002	0.002	0.005	-	0.005	-	0.005	-	-
	T3	C1221	99.7	-	0.002	-	-	-	-	0.01	-	—	-	-
Oxygen Free Copper	TU0	C1011	99.99	0.0003	0.0001	0.0004	0.0005	0.001	0.001	0.0005	0.0002	0.0015	0.0001	0.0005
	TU1	C1020	99.97	0.002	0.001	0.002	0.002	0.004	0.002	0.003	0.002	0.004	0.003	0.002
	TU2	C1020	99.95	0.002	0.001	0.002	0.002	0.004	0.002	0.004	0.002	0.004	0.003	0.003

Grade (JIS)	Temper	Vickers Hardness (HV)	Tensile Strength (Mpa)	Elongation (%)
C1100C1201C1220etc.	M (Soft)	≤70	≥195	≥30
	Y4 (1/4H)	60-95	215-295	≥25
	Y2 (1/2H)	80-110	245-345	≥8
	Y (Full Hard)	90-120	295-395	≥3
	T (Extra Hard)	≥110	≥350	-
